Tutorial: Model order reduction with machine learning methods

Recent success of machine learning methods such as artificial neural networks or kernel approaches led to the development of several methods for model order reduction using machine learning surrogates. pyMOR provides the functionality for a simple approach developed by Hesthaven and Ubbiali in [HU18]. For training and evaluation of the neural networks, PyTorch is used. Kernel methods are implemented in pyMOR based on the vectorial kernel orthogonal greedy algorithm (VKOGA), see VKOGARegressor.

In this tutorial we will learn about feedforward neural networks and greedy kernel methods, the basic idea of the approach by Hesthaven and Ubbiali, and how to use it in pyMOR.

Feedforward neural networks

We aim at approximating a mapping \(h\colon\mathcal{P}\rightarrow Y\) between some input space \(\mathcal{P}\subset\mathbb{R}^p\) (in our case the parameter space) and an output space \(Y\subset\mathbb{R}^m\) (in our case the reduced space), given a set \(S=\{(\mu_i,h(\mu_i))\in\mathcal{P}\times Y: i=1,\dots,N\}\) of samples, by means of an artificial neural network. In this context, neural networks serve as a special class of functions that are able to “learn” the underlying structure of the sample set \(S\) by adjusting their weights. More precisely, feedforward neural networks consist of several layers, each comprising a set of neurons that are connected to neurons in adjacent layers. A so-called “weight” is assigned to each of those connections. The weights in the neural network can be adjusted while fitting the neural network to the given sample set. For a given input \(\mu\in\mathcal{P}\), the weights between the input layer and the first hidden layer (the one after the input layer) are multiplied with the respective values in \(\mu\) and summed up. Subsequently, a so-called “bias” (also adjustable during training) is added and the result is assigned to the corresponding neuron in the first hidden layer. Before passing those values to the following layer, a (non-linear) activation function \(\rho\colon\mathbb{R}\rightarrow\mathbb{R}\) is applied. If \(\rho\) is linear, the function implemented by the neural network is affine, since solely affine operations were performed. Hence, one usually chooses a non-linear activation function to introduce non-linearity in the neural network and thus increase its approximation capability. In some sense, the input \(\mu\) is passed through the neural network, affine-linearly combined with the other inputs and non-linearly transformed. These steps are repeated in several layers.

The following figure shows a simple example of a neural network with two hidden layers, an input size of two and an output size of three. Each edge between neurons has a corresponding weight that is learnable in the training phase.

To train the neural network, one considers a so-called “loss function”, that measures how the neural network performs on the training parameters \(S\), i.e. how accurately the neural network reproduces the output \(h(\mu_i)\) given the input \(\mu_i\). The weights of the neural network are adjusted iteratively such that the loss function is successively minimized. To this end, one typically uses a Quasi-Newton method for small neural networks or a (stochastic) gradient descent method for deep neural networks (those with many hidden layers).

In pyMOR, there exists a training routine for neural networks. This procedure is part of the fit-method of the NeuralNetworkRegressor and it is not necessary to write a custom training algorithm for each specific problem. The training data is automatically split in a random fashion into training and validation set. However, it is sometimes necessary to try different architectures for the neural network to find the one that best fits the problem at hand. In the regressor, one can easily adjust the number of layers and the number of neurons in each hidden layer, for instance. Furthermore, it is also possible to change the deployed activation function.

A possibility to use feedforward neural networks in combination with reduced basis methods will be discussed below. First, we introduce a different machine learning technique based on kernel interpolation. Both methods can be used within pyMOR for model order reduction. It is further possible to employ any regressor for regression problems from scikit-learn.

Greedy kernel methods

Another strategy for function approximation implemented in pyMOR is given by kernel methods. The approach is based on approximations constructed as linear combinations of a kernel function centered at a set of suitably selected points, the so-called centers. The function used for interpolation respectively regression of scalar-valued outputs therefore takes the form

\[\Phi(x) = \sum\limits_{i=1}^{n} \alpha_i\cdot k(x,x_i)\]

for \(x\in\mathbb{R}^d\) with coefficients \(\alpha_1,\ldots,\alpha_n\in\mathbb{R}\) and centers \(x_1,\ldots,x_n\in\mathbb{R}^d\).

For simplicty, we restrict the description given here to the case of an interpolation problem for given data points \(S=\{(\mu_i,h(\mu_i))\in\mathbb{R}^d\times\mathbb{R}: i=1,\ldots,N\}\). For our application later on, we will assume that \(\mu_1,\ldots,\mu_N\in\mathcal{P}\). Using a representer theorem, one can show that the centers in the interpolant should be chosen as the data points themselves, i.e. \(n=N\) and \(x_i=\mu_i\) for \(i=1,\ldots,n\). The coefficients \(\alpha_i\) can then be computed as solution of a linear system using the interpolation conditions. To be more precise,

\[K\alpha=f,\qquad K=[k(\mu_i,\mu_j)]_{i,j=1}^{n},\qquad f=[h(\mu_i)]_{i=1}^{n}.\]

Typically, one is interested in a sparse approximation of the kernel interpolant, in the sense that only a small subset of the set of data points is used as centers. The remaining question is how to select the data points for the kernel surrogate. A possible strategy is to use a greedy method for center selection, similar to the greedy algorithm for parameter selection described in Tutorial: Building a Reduced Basis. The implementation in pyMOR actually makes use of the same weak greedy algorithm as for reduced basis construction. More details on the iterative construction of the kernel surrogates can be found in the documentation of the VKOGARegressor and in [WH13] as well as in [SH21].

A non-intrusive reduced order method using machine learning

We now assume that we are given a parametric pyMOR Model for which we want to compute a reduced order surrogate Model using a machine learning method. In this example, we consider the following two-dimensional diffusion problem with parametrized diffusion, right hand side and Dirichlet boundary condition:

\[-\nabla \cdot \big(\sigma(x, \mu) \nabla u(x, \mu) \big) = f(x, \mu),\quad x=(x_1,x_2) \in \Omega,\]

on the domain \(\Omega:= (0, 1)^2 \subset \mathbb{R}^2\) with data functions \(f((x_1, x_2), \mu) = 10 \cdot \mu + 0.1\), \(\sigma((x_1, x_2), \mu) = (1 - x_1) \cdot \mu + x_1\), where \(\mu \in (0.1, 1)\) denotes the parameter. Further, we apply the Dirichlet boundary conditions

\[u((x_1, x_2), \mu) = 2x_1\mu + 0.5,\quad x=(x_1, x_2) \in \partial\Omega.\]

We discretize the problem using pyMOR’s built-in discretization toolkit as explained in Tutorial: Using pyMOR’s discretization toolkit:

from pymor.basic import *

problem = StationaryProblem(
      domain=RectDomain(),

      rhs=LincombFunction(
          [ExpressionFunction('10', 2), ConstantFunction(1., 2)],
          [ProjectionParameterFunctional('mu'), 0.1]),

      diffusion=LincombFunction(
          [ExpressionFunction('1 - x[0]', 2), ExpressionFunction('x[0]', 2)],
          [ProjectionParameterFunctional('mu'), 1]),

      dirichlet_data=LincombFunction(
          [ExpressionFunction('2 * x[0]', 2), ConstantFunction(1., 2)],
          [ProjectionParameterFunctional('mu'), 0.5]),

      name='2DProblem'
  )

fom, _ = discretize_stationary_cg(problem, diameter=1/50)

Since we employ a single Parameter, and thus use the same range for each parameter, we can create the ParameterSpace using the following line:

parameter_space = fom.parameters.space((0.1, 1))

The main idea of the approach by Hesthaven et al. is to approximate the mapping from the Parameters to the coefficients of the respective solution in a reduced basis by means of a neural network. Thus, in the online phase, one performs a forward pass of the Parameters through the neural networks and obtains the approximated reduced coordinates. To derive the corresponding high-fidelity solution, one can further use the reduced basis and compute the linear combination defined by the reduced coefficients. The reduced basis is created via POD.

The method described above is “non-intrusive”, which means that no deep insight into the model or its implementation is required and it is completely sufficient to be able to generate full order snapshots for a randomly chosen set of parameters. This is one of the main advantages of the proposed approach, since one can simply train a neural network, check its performance and resort to a different method if the neural network does not provide proper approximation results.

Further, the method is actually independent of the particular machine learning approach. It is therefore possible to use, for instance, kernel methods instead of neural networks as originally proposed in [HU18]. In pyMOR, the implementation can deal with any regressor fulfilling the scikit-learn interface. The neural networks and the kernel methods are implemented in pyMOR in such a way that they also follow the scikit-learn interface and the reductor only requires such a regressor. In this tutorial, we will compare neural networks and kernel methods and show how they can be trained and used in the context of model order reduction.

To train the machine learning surrogates, we create a set of training parameters consisting of 100 randomly chosen parameter values:

training_parameters = parameter_space.sample_uniformly(100)

In this tutorial, we construct the reduced basis such that no more modes than required to bound the l2-approximation error by a given value are used. The l2-approximation error is the error of the orthogonal projection (in the l2-sense) of the training snapshots onto the reduced basis. That is, we prescribe l2_err in the POD method. It is also possible to determine a relative or absolute tolerance (in the singular values) that should not be exceeded on the training parameters. Further, one can preset the size of the reduced basis. The construction of the reduced basis is independent of the machine learning surrogate and is therefore not part of the reductor. The reduced basis has to be computed beforehand and provided (together with the reduced coeffcients, for instance the coefficients with respect to the reduced basis of the orthogonal projection onto the reduced space) to the reductor. Within the reductor, mainly the training of the regressor using the correct data formats is performed and suitable reduced models are constructed.

We start by collecting the training snapshots associated to the training parameters:

training_snapshots = fom.solution_space.empty(reserve=len(training_parameters))
for mu in training_parameters:
    training_snapshots.append(fom.solve(mu))

We now initialize regressors for feedforward neural networks

from pymor.algorithms.ml.nn import FullyConnectedNN, NeuralNetworkRegressor
neural_network = FullyConnectedNN(hidden_layers=[30, 30, 30])
nn_regressor = NeuralNetworkRegressor(neural_network, tol=1e-3)

and kernel methods

from pymor.algorithms.ml.vkoga import GaussianKernel, VKOGARegressor
kernel = GaussianKernel(length_scale=1.0)
vkoga_regressor = VKOGARegressor(kernel=kernel, criterion='fp', max_centers=30, tol=1e-6, reg=1e-12)

Finally, we construct data-driven reductors using the different regressors and call the respective reduce-method to start the training process:

from pymor.reductors.data_driven import DataDrivenPODReductor
nn_reductor = DataDrivenPODReductor(training_parameters, training_snapshots,
                                    regressor=nn_regressor, pod_params={'l2_err': 1e-5})
nn_rom = nn_reductor.reduce()

vkoga_reductor = DataDrivenPODReductor(training_parameters, training_snapshots,
                                       regressor=vkoga_regressor, pod_params={'l2_err': 1e-5})
vkoga_rom = vkoga_reductor.reduce()

We are now ready to test our reduced models by solving for a random parameter value the full problem and the reduced models and visualize the result:

mu = parameter_space.sample_randomly()

U = fom.solve(mu)
# Neural network based model
U_red_nn = nn_rom.solve(mu)
U_red_nn_recon = nn_reductor.reconstruct(U_red_nn)
# Kernel based model
U_red_vkoga = vkoga_rom.solve(mu)
U_red_vkoga_recon = vkoga_reductor.reconstruct(U_red_vkoga)

fom.visualize((U, U_red_nn_recon, U_red_vkoga_recon),
              legend=(f'Full solution for parameter {mu}', f'Reduced solution using NN for parameter {mu}',
                      f'Reduced solution using VKOGA for parameter {mu}'))

Finally, we measure the error of our neural network and kernel surrogates and the performance in terms of computational speedup compared to the solution of the full order problem for some test parameters. To this end, we sample randomly some parameter values from our ParameterSpace:

test_parameters = parameter_space.sample_randomly(10)

Next, we create empty solution arrays for the full and reduced solutions and an empty list for the speedups:

U = fom.solution_space.empty(reserve=len(test_parameters))
U_red_nn = fom.solution_space.empty(reserve=len(test_parameters))
U_red_vkoga = fom.solution_space.empty(reserve=len(test_parameters))

speedups_nn = []
speedups_vkoga = []

Now, we iterate over the test parameters, compute full and reduced solutions to the respective parameters and measure the speedup:

import time

for mu in test_parameters:
    tic = time.perf_counter()
    U.append(fom.solve(mu))
    time_fom = time.perf_counter() - tic

    # Neural network based model
    tic = time.perf_counter()
    U_red_nn.append(nn_reductor.reconstruct(nn_rom.solve(mu)))
    time_red_nn = time.perf_counter() - tic
    speedups_nn.append(time_fom / time_red_nn)

    # Kernel based model
    tic = time.perf_counter()
    U_red_vkoga.append(vkoga_reductor.reconstruct(vkoga_rom.solve(mu)))
    time_red_vkoga = time.perf_counter() - tic
    speedups_vkoga.append(time_fom / time_red_vkoga)

We can now derive the absolute and relative errors on the training parameters as

absolute_errors_nn = (U - U_red_nn).norm()
relative_errors_nn = absolute_errors_nn / U.norm()

absolute_errors_vkoga = (U - U_red_vkoga).norm()
relative_errors_vkoga = absolute_errors_vkoga / U.norm()

The average absolute errors amount to

import numpy as np

print(f"Neural network: {np.average(absolute_errors_nn)}")
print(f"Kernel method: {np.average(absolute_errors_vkoga)}")

Neural network: 0.03632996419304817
Kernel method: 0.01542760170027908

On the other hand, the average relative errors are

print(f"Neural network: {np.average(relative_errors_nn)}")
print(f"Kernel method: {np.average(relative_errors_vkoga)}")

Neural network: 0.00044224982325618623
Kernel method: 0.00017333923030863943

Using machine learning results in the following median speedups compared to solving the full order problem:

print(f"Neural network: {np.median(speedups_nn)}")
print(f"Kernel: {np.median(speedups_vkoga)}")

Neural network: 12.892250783203528
Kernel: 27.29118224654107

Since DataDrivenReductor only uses the provided training data, the approach presented here can easily be applied to Models originating from external solvers, without requiring any access to Operators internal to the solver. Examples using FEniCS for stationary and instationary problems together with the DataDrivenReductor are provided in data_driven_fenics and data_driven_instationary. Furthermore, the strategy is also applicable when no full-order model is available at all. Given a set of training snapshots (for instance read from a file), a reduced basis can be computed using a data-driven compression method such as POD, the snapshots can be projected onto the reduced basis and the machine learning training is handled by the data-driven reductor as shown before.

Direct approximation of output quantities

Thus far, we were mainly interested in approximating the solution state \(u(\mu)\equiv u(\cdot,\mu)\) for some parameter \(\mu\). If we consider an output functional \(\mathcal{J}(\mu):= J(u(\mu), \mu)\), one can use the reduced solution \(u_N(\mu)\) for computing the output as \(\mathcal{J}(\mu)\approx J(u_N(\mu),\mu)\). However, when dealing with supervised machine learning, one could also think about directly learning the mapping from parameter to output. That is, one can use a machine learning surrogate to approximate \(\mathcal{J}\colon\mathcal{P}\to\mathbb{R}^q\), where \(q\in\mathbb{N}\) denotes the output dimension.

In the following, we will extend our problem from the last section by an output functional and use the DataDrivenReductor with the argument target_quantity='output' to derive a reduced model that can solely be used to solve for the output quantity without computing a reduced state at all.

For the definition of the output, we define the output of out problem as the l2-product of the solution with the right hand side respectively Dirichlet boundary data of our original problem:

problem = problem.with_(outputs=[('l2', problem.rhs), ('l2_boundary', problem.dirichlet_data)])

Consequently, the output dimension is \(q=2\). After adjusting the problem definition, we also have to update the full order model to be aware of the output quantities:

fom, _ = discretize_stationary_cg(problem, diameter=1/50)

We can now use again the DataDrivenReductor (for simplicity we only consider kernel methods here) and initialize the reductor using output data:

training_outputs = []
for mu in training_parameters:
    training_outputs.append(fom.output(mu)[:, 0])
training_outputs = np.array(training_outputs)

from pymor.reductors.data_driven import DataDrivenReductor
vkoga_output_regressor = VKOGARegressor(kernel=kernel, criterion='fp', max_centers=30, tol=1e-6, reg=1e-12)
output_reductor = DataDrivenReductor(training_parameters, training_outputs,
                                     regressor=vkoga_output_regressor, target_quantity='output')

Observe that we now specified target_quantity='output' instead of the default value target_quantity='solution' when creating the reductor. On the other hand, we do not need a reduced basis now since we are solely interested in an approximation of the output.

Similar to the DataDrivenReductor with target_quantity='solution', we can call reduce to obtain a reduced order model. In this case, reduce trains the machine learning surrogate to approximate the mapping from parameter to output directly. Therefore, we can only use the resulting reductor to solve for the outputs and not for state approximations. The DataDrivenReductor with target_quantity='solution' though can be used to do both by calling solve respectively output (if we had initialized the DataDrivenReductor with target_quantity='solution' and the problem including the output quantities).

We now perform the reduction and run some tests with the resulting DataDrivenModel:

output_rom = output_reductor.reduce()

outputs = []
outputs_red = []
outputs_speedups = []

for mu in test_parameters:
    tic = time.perf_counter()
    outputs.append(fom.output(mu=mu))
    time_fom = time.perf_counter() - tic

    tic = time.perf_counter()
    outputs_red.append(output_rom.output(mu=mu))
    time_red = time.perf_counter() - tic

    outputs_speedups.append(time_fom / time_red)

outputs = np.squeeze(np.array(outputs))
outputs_red = np.squeeze(np.array(outputs_red))

outputs_absolute_errors = np.abs(outputs - outputs_red)
outputs_relative_errors = outputs_absolute_errors / np.abs(outputs)

The average absolute error (component-wise) on the test parameters is given by

np.average(outputs_absolute_errors)

np.float64(0.000964711635716864)

The average relative error is

np.average(outputs_relative_errors)

np.float64(0.0002433363288621622)

and the median of the speedups amounts to

np.median(outputs_speedups)

np.float64(20.490824597471082)

Machine learning methods for instationary problems

To solve instationary problems using machine learning, we have extended the DataDrivenReductor to also treat instationary cases, where time is treated either as an additional parameter (see [WHR19]) or the whole time trajectory can be predicted at once. In the first case, the input, together with the current time instance, is passed to the machine learning surrogate in each time step to obtain reduced coefficients. In the second case, the parameter is used as input and the of the machine learning surrogate is the complete time trajectory of reduced coefficients. In the same fashion, setting target_quantity='output' yields a reduced model for prediction of output trajectories without requiring information about the solution states.

Instationary machine learning reductors in practice

In the following we apply different machine learning surrogates to a parametrized parabolic equation. First, we import the parametrized heat equation example from examples:

from pymor.models.examples import heat_equation_example
fom = heat_equation_example()
product = fom.h1_0_semi_product

We further define the parameter space:

parameter_space = fom.parameters.space(1, 25)

Additionally, we sample training and test parameters from the respective parameter space:

training_parameters = parameter_space.sample_uniformly(15)
test_parameters = parameter_space.sample_randomly(10)

To check how the different reduced models perform, we write a simple function that measures the errors and the speedups on a set of test parameters:

def compute_errors(rom, reductor):
    speedups = []

    U = fom.solution_space.empty(reserve=len(test_parameters))
    U_red = fom.solution_space.empty(reserve=len(test_parameters))

    for mu in test_parameters:
        tic = time.time()
        u_fom = fom.solve(mu)[1:]
        U.append(u_fom)
        time_fom = time.time() - tic

        tic = time.time()
        u_red = reductor.reconstruct(rom.solve(mu))[1:]
        U_red.append(u_red)
        time_red = time.time() - tic

        speedups.append(time_fom / time_red)

    relative_errors = (U - U_red).norm2() / U.norm2()

    return relative_errors, speedups

We now run the DataDrivenReductor using different machine learning surrogates (VKOGA, VKOGA with time-vectorization, fully-connected neural network) and evaluate the performance of the resulting reduced models:

training_snapshots = fom.solution_space.empty(reserve=len(training_parameters))
for mu in training_parameters:
    training_snapshots.append(fom.solve(mu))

It is often useful for the machine learning training to scale inputs and outputs, for instance using scikit-learn’s MinMaxScaler. This will be incorporated below as well:

from sklearn.preprocessing import MinMaxScaler

vkoga_regressor = VKOGARegressor()
vkoga_reductor = DataDrivenPODReductor(training_parameters, training_snapshots,
                                       regressor=vkoga_regressor, T=fom.T, time_vectorized=False,
                                       input_scaler=MinMaxScaler(), output_scaler=MinMaxScaler(),
                                       pod_params={'modes': 20})
vkoga_rom = vkoga_reductor.reduce()
rel_errors_vkoga, speedups_vkoga = compute_errors(vkoga_rom, vkoga_reductor)

vkoga_regressor_tv = VKOGARegressor()
vkoga_reductor_tv = DataDrivenPODReductor(training_parameters, training_snapshots,
                                          regressor=vkoga_regressor_tv, T=fom.T, time_vectorized=True,
                                          input_scaler=MinMaxScaler(), output_scaler=MinMaxScaler(),
                                          pod_params={'modes': 20})
vkoga_rom_tv = vkoga_reductor_tv.reduce()
rel_errors_vkoga_tv, speedups_vkoga_tv = compute_errors(vkoga_rom_tv, vkoga_reductor_tv)

nn_regressor = NeuralNetworkRegressor(tol=None, restarts=0)
nn_reductor = DataDrivenPODReductor(training_parameters, training_snapshots,
                                    regressor=nn_regressor, T=fom.T, time_vectorized=False,
                                    input_scaler=MinMaxScaler(), output_scaler=MinMaxScaler(),
                                    pod_params={'modes': 20})
nn_rom = nn_reductor.reduce()
rel_errors_nn, speedups_nn = compute_errors(nn_rom, nn_reductor)

We finally print the results:

print('Results for the state approximation:')
print('====================================')
print()
print('Approach by Hesthaven and Ubbiali using feedforward ANNs:')
print('---------------------------------------------------------')
print(f'Average relative error: {np.average(rel_errors_nn)}')
print(f'Median of speedup: {np.median(speedups_nn)}')
print()
print('Approach by Hesthaven and Ubbiali using VKOGA:')
print('----------------------------------------------')
print(f'Average relative error: {np.average(rel_errors_vkoga)}')
print(f'Median of speedup: {np.median(speedups_vkoga)}')
print()
print('Approach by Hesthaven and Ubbiali using VKOGA (time-vectorized):')
print('----------------------------------------------------------------')
print(f'Average relative error: {np.average(rel_errors_vkoga_tv)}')
print(f'Median of speedup: {np.median(speedups_vkoga_tv)}')

Results for the state approximation:
====================================

Approach by Hesthaven and Ubbiali using feedforward ANNs:
---------------------------------------------------------
Average relative error: 0.026686081534930486
Median of speedup: 7.951136261558564

Approach by Hesthaven and Ubbiali using VKOGA:
----------------------------------------------
Average relative error: 0.13061070498143398
Median of speedup: 8.51841353883811

Approach by Hesthaven and Ubbiali using VKOGA (time-vectorized):
----------------------------------------------------------------
Average relative error: 2.8808010537089745e-06
Median of speedup: 22.743413440271674

We observe that in this example, the time-vectorized version of VKOGA performs best in terms of accuracy and speedup.

Download the code: tutorial_mor_with_ml.md tutorial_mor_with_ml.ipynb
